Aufbauleuchte Miniten TB 300 LED 1700lm 12W 3000K IP66

Produktbeschreibung

Produktbeschreibung

TB 300 is a ceiling fitting equipped with high efficiency COB LEDs. Its particular shape provides a uniform light distribution, without glaring. The linear design, featuring an elegant hatched surface, allows the product to be well integrated in halls, entrances, lounges, arcades both in residential and in hospitality areas. The front housing with the safety glass is hinged to the gear housing, for an easy installation of the fitting. High protection rating IP65.

TB 300 is a registered design model.

PRODUCT CODE	COLOR
185103	Silver, on demand
185104	White, on demand
GENERAL SPECIFICATIONS
Product Type	Ceiling lights,Wall-bracket
Mounting Type	Ceiling - surface,Wall - surface
Indoor/Outdoor Lights	Outdoor
Applications	Arcades,Entrances,Halls,Terraces
LIGHTING SPECIFICATIONS
Lamp Description	LED 1700lm 12W 3000K CRI85
Nominal Lumens On Thermal Regime (Lm)	1700
Efficiency L.O.R. (%)	70
Delivered Lumens (Lm)	1190
Lamp Wattage (W)	12
Color Temperature (K)	3000
Average Lamp Life (H)	L80B10 50.000
Photobiological Risk Group	RG1
PHYSICAL SPECIFICATIONS
Body	Die-cast aluminium
Finishes	Polyester painted, with a special antioxidising pretreatment,Polyester painted
Closing Screen	Extra clear tempered (8 mm.) safety glass, bevel-grinded and acid-etched on both sides
Screws	Stainless steel
ELECTRICAL SPECIFICATIONS
Glow Wire (°C)	850
Driver	Included
Driver Mounting	Integrated
Cable Gland	PG9
Voltage (V)	220/240
Frequency (Hz)	50/60
WEIGHT AND DIMENSIONS
Shape	Round
External Diameter (Mm)	320
Height (Mm)	85
Weight (Kg)	2.2
OPTICAL SPECIFICATIONS
Aiming	Fixed
Light Distribution	Symmetric
Light Emission	Direct
Light Beam	120°

Die folgende Miniten Wandleuchte gehört zur gleicher Designerlinie:
