- Produktbeschreibung
Architectural fitting for up-down lighting, uses high efficiency LEDs. It features a high protection rating and a special surface pre-treatment. It is therefore particularly suitable and resistant for outdoor applications. The wall-frame allows an easy installation and wiring. IP66.
PRODUCT CODE | COLOR |
10531243 | Silver |
GENERAL SPECIFICATIONS | |
Product Type | Wall-bracket |
Mounting Type | Wall - surface |
Indoor/Outdoor Lights | Outdoor |
Applications | Arcades,Display areas,Façades of buildings,Shopping centres,Walkways |
LIGHTING SPECIFICATIONS | |
Lamp Description | LED 2x390lm 2x3W 3000K |
Nominal Lumens On Thermal Regime (Lm) | 390 |
Efficiency L.O.R. (%) | 73,6 |
Delivered Lumens (Lm) | 287 |
Lamp Wattage (W) | 3 |
Color Temperature (K) | 3000 |
Average Lamp Life (H) | L80B10 50.000 |
Photobiological Risk Group | RG1 |
Number Of Lamps | 2 |
PHYSICAL SPECIFICATIONS | |
Body | Die-cast aluminium |
Finishes | Metal paint with a special anti-oxidising treatment |
Closing Screen | Tempered 3mm, shockproof and heat resistant |
Frame | Die-cast aluminium |
Gaskets | Silicone |
Screws | Stainless steel |
ELECTRICAL SPECIFICATIONS | |
Driver | Included |
Driver Mounting | Integrated |
Cable Gland | Nickel-plated brass cable gland M12x1, 5 |
Voltage (V) | 230/240 |
Frequency (Hz) | 50/60 |
WEIGHT AND DIMENSIONS | |
Length (Mm) | 125 |
Width (Mm) | 90 |
Weight (Kg) | 1 |
OPTICAL SPECIFICATIONS | |
Aiming | Fixed |
Light Distribution | Symmetric |
Light Emission | Bi-directional |
Light Beam | 60/60 |
Die folgende Miniten Deckenleuchte gehört zur gleicher Designerlinie:
